Radiation Detection
RadWall Environmental Radiation Monitor The RadWall environmental radiation monitor can accurately measure the ambient air absorbed dose rate (X, γ), alarm the regional radiation dose rate exceeding the threshold, avoid personnel entering the radiation danger area, and ensure the radiation safety of the working environment.

RadWall helps users to establish a comprehensive and diverse environment radiation monitoring network to provide data support for environmental radiation safety. Connect with RadSys intelligent radiation monitoring system through wireless communication to realize automatic data recording, visual display and in-depth data analysis.

RadWall uses a built-in detector, which can be used as a local display alarm unit (ADU). The integrated structure design is easy to install and adjust.

Specification

  • Model：RadWall
  • Detector：Scintillation detector
  • Dose rate：0.01μGy/h ~ 10mGy/h
  • Relative inherent error：Not more than ±15%
  • Alarm threshold：Continuously adjustable within the range
  • Alarm method：Audible alarm
  • Data transmission：Wireless communication
  • Power supply：Mains
  • Size：D 175mm, H 50mm
